Macchina per il packaging secondario
di confezioni di pannolini per adulti e bambini, assorbenti,
rotoli di carta e altre tipologie di prodotti
Packaging material thickness:
Polyethylene (PE): from 35 to 90 My (microns) Density 0,87/0,93;
Different film thickness TBD;
Max. poly reel diameter: Up to 450 mm;
Max. poly reel width: Up to 2500 mm.
Change-over time:
Max. 25 min. – based on staff training and performances.
Operating panel HMI
Boom mounted rotating “HMI” enabling machine control and management.
The system allows to:
- Monitor technical functions, check them and adjust them for optimum performance;
- Store format parameters in order to facilitate format changeovers;
- Detect the trouble shooting machine diagnostics;
- In English and Italian (on request in addition the customer’s language).
Finished Bundle dimensions
| Width | 380 mm – 850 mm (with ACTIVE PULL TECH 240 mm – 600mm) |
| Length | 380 mm – 850 mm or 1200* mm |
| Heigth | 180 mm – 400 mm |
| Overlapping | 50/60 mm |
| Pitch (length) | max 1400 mm |
| Handle (optional) | 50/60 mm |
| Max Reel (width) | 2500 mm |
Product handling:
With robot ABB IRB 1200 6 axes (diapers adult & baby).
Collating unit (tissue roll).
Bundle Speed:
Up to 22 cycles/min.
*Up to 10 cycles/min with a double stroke insertion sequence.
NB: Production speed depends on the quality of the product coming from up-stream, on packaging material characteristics and final bundle dimensions required.
Diapers
Tissue
Tissue
